SKU: FX-BP250SL-II
The Nexus BP-250SL is a V-Mount battery with a capacity of 14.4V / 17.4Ah / 251Wh and a maximum output of 14.4V / 18A. It features two D-Tap in/out ports, one USB-C port supporting up to 100W input/output, and one USB-A output port. Equipped with an intelligent PCB, the battery communicates with SONY and RED cameras, ensuring seamless integration and reliable performance.
Description
This 251Wh battery features a shockproof hard case with rubber protection and an LCD Display, offering superior durability and a sleek, professional design. With a high output of 18A / 250W, it delivers the power needed for demanding equipment. The rechargeable Li-ion cells are free from memory effect, ensuring consistent performance over time.
An intelligent PCB design provides multi-layer protection against overheating, overcharging, over-discharging, and overcurrent, keeping both the battery and your devices safe. It supports SONY and RED communication protocols, allowing compatible cameras to display real-time battery data such as capacity, voltage, and remaining percentage.
The internal battery pack uses a non-wire assembly process for enhanced stability and reliability. It includes a USB-C port with bidirectional PD 100W fast charging, a USB-A output port, and two D-Tap in/out ports. These allow you to power cameras, high-draw LED lights, and also charge the battery using a D-Tap charger.
Designed to perform in extreme conditions, the battery operates reliably in temperatures ranging from -20°C to +55°C. Its reinforced internal structure improves drop resistance, while protective rubber caps on the D-Tap and USB-A ports enhance durability. A metal V-lock mount provides added strength and wear-resistance for long-term, professional use.
- Rugged shockproof casing with rubberized protection and a LCD Screen
- 18A/250W high-power output, with a peak output power of 150W
- Rechargeable Li-ion battery with no memory effect
- Advanced PCB design providing multi-layer protection against overheat, overcharge, overdischarge, and overcurrent
- Compatible with SONY/RED communication protocols, enabling the camera to display battery capacity, voltage, percentage, and other data
- Wire-free assembly process for the internal battery pack, ensuring enhanced stability
- USB-C port supporting bidirectional PD fast charging up to 100W
- 1*USB-A output port
- 2*D-Tap output/input which can supply power for both camera and high-power LED light and be charged by D-tap charger
- Working temperature: -20°C~+55°C
- Independent battery pack and shell structure for enhanced drop resistance
- D-Tap and USB-A ports with protective rubber caps
- Fitted with a metal V-lock, providing increased solidity and wear resistance
Additional information
| Voltage | 14.4 V |
|---|---|
| Capacity | 17.4Ah/251Wh |
| Load | 18A(Max)/250W(Max) |
| Mount Type | V-Mount |
| D-Tap In- & Output | 2*10-16.8V/18A(Max) |
| USB-C In- & Output | 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A (PD 100W Max) (USB-C cable with built-in E-Mark chip supports 100W input/output) |
| USB-A Output | 5V/2A, 9V/2A, 12V/1.5A |
| Operating Temperature | -20°C to +55°C |
| Charging Temperature | 0°C to +40°C |
| Storage Temperature | -20°C to +45°C |
| Dimensions | 154(L) × 100(W) × 85(H)mm |
| Weight | 1580g |
